Non-Standard Aircraft
In the symphony of gears and circuits, industrial automation pirouettes across factories and assembly lines. Picture the Automatic Mobile Flipping Equipment, gracefully turning phones right-side-up, while labor fatigue wanes and quality control thrives. The tire Inflator Equipment dances, infusing life into rubber, ensuring road-ready companions. On the conveyor belt, the V20 Servo Drive Housing Feeding Equipment orchestrates precision—seamless assembly lines, reduced errors, and engineers grinning ear to ear. Meanwhile, the vigilant Bearing Outer Ring Inner Wall Automatic Detection Equipment scrutinizes with laser-like precision, assuring flawless components. This dance propels us toward a harmonious future where machines and humans waltz together.
1. Introduction:
This device is used for loading and sorting the V20 servo drive casing. As the starting station in the automation system, this station plays a role in connecting with manual labor and transferring incoming materials from disorder to order. The equipment consists of two racks, including non-standard racks and standard racks. The non-standard rack includes a three-axis truss, a visual positioning system, a hoist, and a docking part for the incoming material trolley; The main function of non-standard racks is to connect with the main line and install electrical components in the main control section. The action process of this device is: manually place the material boxes filled with the drive casing layer by layer onto the trolley, push the trolley into the equipment, and at the same time, the empty material trolley is also pushed into the equipment. The truss and visual system realize the positioning, grasping, and placement of the casing, and at the same time, place the empty material boxes onto the empty material trolley. After all loading is completed, manually pull the trolley away and place the material again.
2. Features:
(1) Reduce employee labor intensity
(2) Realize automatic feeding
(3) Visual positioning and grasping, intelligent feeding method
3. The significance of the project:
Provide stable incoming material solutions for customers to achieve automated production throughout the entire line.
1. Introduction:
Use a ball gauge to detect any protrusions on the inner wall of the outer ring of the bearing due to processing defects. The cylinder drives the ball gauge to move up and down for detection. The incoming products are sorted and positioned using a multi-station turntable. Install a powerful sensor at the end of the cylinder. Once there is a boss on the inner wall of the product, the feedback pressure from the force sensor exceeds the limit, and it is judged as NG.
2. Features:
(1) Fast speed, detecting 70 items per minute
(2) High detection accuracy, capable of detecting protrusions larger than 0.1mm
3. Project significance:
Improved customer productivity, reduced employee labor intensity, improved product testing accuracy and stability, facilitated production management, and achieved full line automation.
1.Introduction:
This equipment is used for automatic testing and automatic board division of PBO board of V90. The station is divided into two cells, each of which is performed by a robot, and the tray is reflowed between the two units by a double-layer reflow line. It is compatible with the two PBO power boards of V20 inverter FSA and FSB, and the whole process is carried out unmanned automatically.
2.Features:
(1) Unmanned automatic operation
(2) The equipment is stable and the efficiency is high
(3) Flexible design to protect products.
(4) Modular design, convenient and fast maintenance
(5) Intelligent and digital.
3.The significance of the project:
Provide stable test and sub-board solutions for test boards for customer realization products.
1. Equipment Function Introduction:
This device is mainly designed for automotive parts factories and is used for the assembly and welding of parts in automotive airbags. The processing object is the welding of diffusers and thin stainless steel bursting discs. The workstation distribution is robot loading and unloading, automatic loading and unloading of bursting discs, fixture type detection, laser welding workstation, eddy current detection, visual detection workstation, laser coding and reading, and automatic unloading; The MTS, EDIS daily inspection system, and MES traceability system configured in the system can fully monitor the entire lifecycle of product production in real-time.
2. Equipment advantages:
Advanced equipment technology, complete functions, stable performance, and high production capacity; Easy to maintain and operate; And there will be room for expansion for future development, expansion, renovation, and other factors. The design content of this system is systematic, complete, and comprehensive; Traceability of production, storage, and transportation processes to better match client expectations for product quality
3. Project significance:
This equipment can meet the requirement of continuous operation for 50 working weeks, 7 * 24 hours, in the customer's factory throughout the year, and complete the trial run of 1000 consecutive products. During this process, it must involve the replacement of large and small diffusion products, and the equipment capacity Ppk=Cmk>2.
1. This device is used to automatically clean and dry the heat sink with alcohol, and automatically brush the heat dissipation adhesive onto the drive heat sink. The first workstation utilizes the principle of pneumatic vacuum suction and spraying to spray alcohol onto the equipment. And use the principle of a paper roller to automatically wipe alcohol; The second and third stations are the glue brushing stations for different models of products, which use a double blade and wire mesh method to brush the glue to ensure the quality of the brushing.
2. Features:
(1) Ensure cleanliness and adhesive quality
(2) Improve work efficiency
3. The significance of the project:
Assist customers in transitioning from manual to automated cleaning and adhesive brushing.
1. Equipment Function Introduction:
This device is mainly designed for automotive parts factories and is used for the assembly and welding of parts in automotive airbags. The processing object is the welding of diffusers and thin stainless steel bursting discs. The workstation distribution is robot loading and unloading, automatic loading and unloading of bursting discs, fixture type detection, laser welding workstation, eddy current detection, visual detection workstation, laser coding and reading, and automatic unloading; The MTS, EDIS daily inspection system, and MES traceability system configured in the system can fully monitor the entire lifecycle of product production in real-time.
2. Equipment advantages:
Advanced equipment technology, complete functions, stable performance, and high production capacity; Easy to maintain and operate; And there will be room for expansion for future development, expansion, renovation, and other factors. The design content of this system is systematic, complete, and comprehensive; Traceability of production, storage, and transportation processes to better match client expectations for product quality
3. Project significance:
This equipment can meet the requirement of continuous operation for 50 working weeks, 7 * 24 hours, in the customer's factory throughout the year, and complete the trial run of 1000 consecutive products. During this process, it must involve the replacement of large and small diffusion products, and the equipment capacity Ppk=Cmk>2.
1. Equipment Function Introduction:
This device is the core equipment in the assembly of automotive airbags, including mechanisms such as automatic feeding, automatic recycling, resistance welding, automatic gas filling, and automatic detection of small balls; As a necessary equipment for all airbag manufacturers, the system is equipped with MTS, EDIS daily inspection system, and MES traceability system, which can fully monitor the entire lifecycle of product production in real-time.
2. Features:
(1) Stable equipment and high efficiency
3. Equipment advantages:
(1) Stable and efficient equipment
(2) Strong product traceability
(3) Top domestic equipment
4. Project significance:
This equipment can meet the requirement of continuous operation for 50 working weeks, 7 * 24 hours, in the customer's factory throughout the year, and complete the trial run of 1000 consecutive products. The equipment capacity Ppk=Cmk>2.
